CC1310F128RGZR Microcontroller MCU SimpleLink™ 32-Bit Arm Cortex-M3 Sub-1 GHz Wireless MCU

CC1310F128RGZR Microcontroller MCU SimpleLink™ 32-Bit Arm Cortex-M3 Sub-1 GHz Wireless MCU

Proeuct Description Of CC1310F128RGZR
CC1310F128RGZR device is a cost-effective, ultra-low-power, Sub-1 GHz RF device from Texas Instruments™ that is part of the SimpleLink™ microcontroller (MCU) platform. The platform consists of Wi-Fi®, Bluetooth® low energy, Sub-1 GHz, Ethernet, Zigbee®, Thread, and host MCUs. These devices all share a common, easy-to-use development environment with a single core software development kit (SDK) and a rich tool set. A one-time integration of the SimpleLink platform enables users to add any combination of devices from the portfolio into their design, allowing 100 percent code reuse when design requirements change.

Specifications Of CC1310F128RGZR

Features Of CC1310F128RGZR
Microcontroller
Powerful Arm® Cortex®-M3 Processor
EEMBC CoreMark® Score: 142
EEMBC ULPBench™ Score: 158
Clock Speed up to 48-MHz
32KB, 64KB, and 128KB of In-System Programmable Flash
8KB of SRAM for Cache
(or as General-Purpose RAM)
20KB of Ultra-Low-Leakage SRAM
2-Pin cJTAG and JTAG Debugging
Supports Over-the-Air (OTA) Update
Ultra-Low-Power Sensor Controller
Can Run Autonomously From the Rest of the System
16-Bit Architecture
2KB of Ultra-Low-Leakage SRAM for Code and Data
Efficient Code-Size Architecture, Placing Parts of
TI-RTOS, Drivers, and Bootloader in ROM
RoHS-Compliant Package
7-mm × 7-mm RGZ VQFN48 (30 GPIOs)
5-mm × 5-mm RHB VQFN32 (15 GPIOs)
4-mm × 4-mm RSM VQFN32 (10 GPIOs)
Peripherals
All Digital Peripheral Pins Can Be Routed to Any GPIO
Four General-Purpose Timer Modules
(Eight 16-Bit or Four 32-Bit Timers, PWM Each)
12-Bit ADC, 200 ksamples/s, 8-Channel Analog MUX
Continuous Time Comparator
Ultra-Low-Power Clocked Comparator
Programmable Current Source
UART
2× SSI (SPI, MICROWIRE, TI)
I2C, I2S
Real-Time Clock (RTC)
AES-128 Security Module
True Random Number Generator (TRNG)
Support for Eight Capacitive Sensing Buttons
Integrated Temperature Sensor
External System
On-Chip Internal DC/DC Converter
Seamless Integration With the SimpleLink™ CC1190 Range Extender
Low Power
Wide Supply Voltage Range: 1.8 to 3.8 V
RX: 5.4 mA
TX at +10 dBm: 13.4 mA
Active-Mode MCU 48 MHz Running Coremark: 2.5 mA (51 µA/MHz)
Active-Mode MCU: 48.5 CoreMark/mA
Active-Mode Sensor Controller at 24 MHz:
0.4 mA + 8.2 µA/MHz
Sensor Controller, One Wakeup Every Second Performing One 12-Bit ADC Sampling: 0.95 µA
Standby: 0.7 µA (RTC Running and RAM and CPU Retention)
Shutdown: 185 nA (Wakeup on External Events)
RF Section
Excellent Receiver Sensitivity –124 dBm Using Long-Range Mode, –110 dBm at 50 kbps
Excellent Selectivity (±100 kHz): 56 dB
Excellent Blocking Performance (±10 MHz):
90 dB
Programmable Output Power up to +15 dBm
Single-Ended or Differential RF Interface
Suitable for Systems Targeting Compliance With Worldwide Radio Frequency Regulations
ETSI EN 300 220, EN 303 204 (Europe)
FCC CFR47 Part 15 (US)
ARIB STD-T108 (Japan)
Wireless M-Bus (EN 13757-4) and IEEE® 802.15.4g PHY
Tools and Development Environment
Full-Feature and Low-Cost Development Kits
Multiple Reference Designs for Different RF Configurations
Packet Sniffer PC Software
Sensor Controller Studio
SmartRF™ Studio
SmartRF Flash Programmer 2
IAR Embedded Workbench® for Arm
Code Composer Studio™ (CCS) IDE
CCS UniFlash

Applications Of CC1310F128RGZR
315-, 433-, 470-, 500-, 779-, 868-, 915-,920-MHz ISM and SRD Systems
Low-Power Wireless Systems With 50-kHz to 5-MHz Channel Spacing
Home and Building Automation
Wireless Alarm and Security Systems
Industrial Monitoring and Control
Smart Grid and Automatic Meter Reading
Wireless Healthcare Applications
Wireless Sensor Networks
Active RFID
IEEE 802.15.4g, IP-Enabled Smart Objects (6LoWPAN), Wireless M-Bus, KNX Systems,Wi-SUN™, and Proprietary Systems
Energy-Harvesting Applications
Electronic Shelf Label (ESL)
Long-Range Sensor Applications
Heat-Cost Allocators
