MCF5282CVM66 Microcontroller MCU ColdFire V2 32-Bit 66MHz Microcontroller MAPBGA-256

MCF5282CVM66 Microcontroller MCU ColdFire V2 32-Bit 66MHz Microcontroller MAPBGA-256

Product Description Of MCF5282CVM66
MCF5282CVM66 is a 32-bit microcontroller (MCU) family based on the ColdFire® V2 core and integrated with Ethernet, CAN and flash (except for MCF5280). These devices offer advanced communications features, a rich peripheral set and a variety of supporting software and development tools.

MCF5282CVM66 is designed to simplify embedded Ethernet-networked MCU applications. With its integrated 10/100 Mbps Ethernet MAC and network-ready applications software, the MCF5282CVM66 can bring standards-based networking to a variety of traditional MCU applications including food service equipment, security systems, vending machines, exercise equipment and industrial controllers. Applications in all of these areas will benefit from networking functions such as web-based user interfaces, network time synchronization and router/gateway functionality for legacy serial protocols.

Specifications Of MCF5282CVM66

Features Of MCF5282CVM66
ColdFire® V2 core delivering 76 (Dhrystone 2.1) MIPS at 80 MHz running from cache/RAM (max running from internal flash 66 MIPS)
Cache (KB): 2 KB I/D
Integrated peripherals
10/100 Ethernet MAC
CAN 2.0B
3 universal aynchronous receive/transmitters (UARTs) with direct memory access (DMA) capability
I²C
Queued serial peripheral interface (QSPI) with four peripheral chip selects
Eight-channel 10-bit queued analog-to-digital converter (ADC)
Four 32-bit timers with capture, compare and DMA capability
Eight 16-bit timer channels for capture, compare and pulse width modulation (PWM)
PITs: Four
