تفاصيل المنتج:
|
| Part Number: | 61082-081602LF | Product: | Receptacles |
|---|---|---|---|
| Number of Positions: | 80 Position | Pitch: | 0.8 mm (0.031 in) |
| Current Rating: | 800 mA | Voltage Rating: | 100 V |
| إبراز: | BergStak 0.80mm mezzanine connectors,80POS receptacle connectors,0.80mm pitch mezzanine connectors,80POS receptacle connectors,0.80mm pitch mezzanine connectors |
||
| Attribute | Value |
|---|---|
| Part Number | 61082-081602LF |
| Product | Receptacles |
| Number of Positions | 80 Position |
| Pitch | 0.8 mm (0.031 in) |
| Current Rating | 800 mA |
| Voltage Rating | 100 V |
61082-081602LF is BergStak Mezzanine Connectors, 0.80mm Pitch, Receptacle, Vertical, Double Row, 80 Positions, 3.70mm (0.146in) Height.
| Series | BergStak® 0.80mm |
|---|---|
| Connector Type | Receptacle, Outer Shroud Contacts |
| Number of Positions | 80 |
| Pitch | 0.031" (0.80mm) |
| Number of Rows | 2 |
| Mounting Type | Surface Mount |
| Features | Board Guide |
| Contact Finish | Gold |
| Contact Finish Thickness | 4.00µin (0.100µm) |
| Mated Stacking Heights | 5mm, 6mm, 7mm, 8mm |
| Height Above Board | 0.146" (3.70mm) |
| Part Number | Package |
|---|---|
| TPS62135 | 11-VQFN |
| MT62F1G64D8WT-031 | 496-FBGA |
| TMC5072 | 48-QFN |
| CS46L41 | WLCSP |
| PI2DBS16212 | 24-TQFN |
| AGFB014R24D1I3V | 2340-BGA |
| AGFB008R16A2I2VB | 1546-BGA |
| AGFD023R31C2E3E | 3184-BGA |
| AGFB012R24C2I3E | 2340-BGA |
| AGFB014R24C2I2V | 2340-BGA |
| AGFD023R25A3E3E | 2581-FBGA |
| AGID019R31B1I1VB | 3184-BGA |
| AGFB019R31C2E2VB | 3184-BGA |
| AGFD023R24C2E1VB | 3184-BGA |
| AGFB019R24C2I1V | 2340-BGA |
| AGFB023R24C2E1V | 2340-BFBGA |
| AGIB027R29B1E2V | 2957-BGA |
| AGIB027R31A2E2V | 3184-BGA |
| AGFB019R24C3I3E | 2340-BFBGA |
| AGFB008R24C2E2VB | 2340-BGA |
| AGIB027R31B2I3E | 3184-FBGA |
| AGFB012R24C2E4F | 2340-BGA |
| AGFB014R24C2E4F | 2340-BGA |
| AGIB023R31B2I2V | 3184-BGA |
| AGFD023R24C3E3V | 2340-BFBGA |
| AGIB022R29A2E2VB | 2957-BFBGA |
| AGIB023R31B2I2VB | 3184-BGA |
| AGIB027R29A2E2VB | 2957-BGA |
| AGIB027R31B2I1VB | 3184-BGA |
| AGID019R31B1E1VB | 3184-BFBGA |
A: Yes, all products are original, new original import is our purpose.
A: We are ISO 9001:2015 Certified Company and member of ERAI.
A: Yes, we support sample order and small order. Sample cost is different according to your order or project.
A: We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
A: We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
