تفاصيل المنتج:
|
| رقم الجزء: | BSC670N25NSFD | مسلسل: | OptiMOS ™ |
|---|---|---|---|
| استنزاف إلى مصدر الجهد (Vdss): | 250 فولت | بوابة المسؤول (Qg) (الحد الأقصى) @ Vgs: | 30 نانو سي @ 10 فولت |
| تبديد السلطة (الحد الأقصى): | 150 واط (ح) | درجة حرارة التشغيل: | -55 درجة مئوية ~ 175 درجة مئوية (TJ) |
BSC670N25NSFD Integrated Circuit Chip 250V N-Channel Power MOSFET Transistors PG-TDSON-8
Product Description Of BSC670N25NSFD
BSC670N25NSFD is 250V, OptiMOS™ N-Channel Power MOSFET Transistors in PG-TDSON-8 package.
OptiMOS™ Fast Diode (FD) 200V, 250V and 300V is optimized for body diode hard commutation. These devices are the perfect choice for hard switching applications such as telecom, industrial power supplies, Class D audio amplifiers, motor control and DC-AC inverter.
Specification Of BSC670N25NSFD
|
Series
|
OptiMOS™
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
Part Status
|
Discontinued at Digi-Key
|
|
FET Type
|
N-Channel
|
|
Technology
|
MOSFET (Metal Oxide)
|
|
Drain to Source Voltage (Vdss)
|
250 V
|
|
Current - Continuous Drain (Id) @ 25°C
|
24A (Tc)
|
|
Drive Voltage (Max Rds On, Min Rds On)
|
10V
|
|
Rds On (Max) @ Id, Vgs
|
67mOhm @ 24A, 10V
|
|
Vgs(th) (Max) @ Id
|
4V @ 90µA
|
|
Gate Charge (Qg) (Max) @ Vgs
|
30 nC @ 10 V
|
|
Vgs (Max)
|
±20V
|
|
Input Capacitance (Ciss) (Max) @ Vds
|
2410 pF @ 125 V
|
|
Power Dissipation (Max)
|
150W (Tc)
|
|
Operating Temperature
|
-55°C ~ 175°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Supplier Device Package
|
PG-TDSON-8-1
|
|
Package / Case
|
8-PowerTDFN
|
Features Of BSC670N25NSFD
N-channel, Normallevel
175°C rated
Excellent gate charge x RDS(on) product(FOM)
Very low on-resistance RDS(on)
Improved hard commutation ruggedness
Optimized hard switching behavior
Industry’s lowest R ds(on)
RoHS compliant - halogen free
Applications Of BSC670N25NSFD
DC-DC converter 48 V-12 V
