تفاصيل المنتج:
|
| رقم الجزء: | STD18N60M6 | Vds - جهد تفكيك مصدر الصرف: | 600 فولت |
|---|---|---|---|
| المعرف - تيار التصريف المستمر: | 13 أ | Rds On - مقاومة مصدر الصرف: | 280 مللي أوم |
| Qg - رسوم البوابة: | 16.8 ن.س | PD - تبديد الطاقة: | 110 واط |
| إبراز: | 600V Power MOSFET,13A MOSFET Transistor,280mOhm N-Channel MOSFET,13A MOSFET Transistor,280mOhm N-Channel MOSFET |
||
| Series | MDmesh™ M6 |
|---|---|
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 600 V |
| Current - Continuous Drain (Id) @ 25°C | 13A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 280mOhm @ 6.5A, 10V |
| Vgs(th) (Max) @ Id | 4.75V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 16.8 nC @ 10 V |
| Vgs (Max) | ±25V |
| Input Capacitance (Ciss) (Max) @ Vds | 650 pF @ 100 V |
| Power Dissipation (Max) | 110W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | TO-252 (DPAK) |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Part Number | Package |
|---|---|
| PCA9420KUKZ | WLCSP-25 |
| PCA9420AUKZ | WLCSP-25 |
| PCA9421UKZ | WLCSP-25 |
| MFS2320BMBB1EP | HVQFN-48 |
| TEA9026T/1Y | 16-SOIC |
| MFS2323BMBA0EP | HVQFN-48 |
| MFS2323BMBA1EP | HVQFN-48 |
| FS2323BMMA0EP | HVQFN-48 |
| TEA9123BTY | 16-SOIC |
| MPF5020CMMACES | 40-VFQFN |
| MFS2622AMBA0AD | 48-LQFP |
| MFS2632AMBA0AD | 48-LQFP |
| MFS2612AMBA0AD | 48-LQFP |
| MFS2621AMDA0AD | 48-LQFP |
| MFS2601AMDA0AD | 48-LQFP |
| MC33XS2410EL | 28-HTSSOP |
| MFS2610AMDA0AD | 48-LQFP |
| MFS2631AMBA0AD | 48-LQFP |
| MFS2620AMDA0AD | 48-LQFP |
| MFS2611AMDA0AD | 48-LQFP |
| MFS2631AMDA0AD | 48-LQFP |
| MFS2611AMBA0AD | 48-LQFP |
| MFS2612AMDA0AD | 48-LQFP |
| MFS2622AMDA0AD | 48-LQFP |
| MFS2602AMDA0AD | 48-LQFP |
| MFS2632AMDA0AD | 48-LQFP |
| MFS2620AMBA0AD | 48-LQFP |
| MFS2601AMBA0AD | 48-LQFP |
| MFS2610AMBA0AD | 48-LQFP |
| PCA9482UKZ | 42-UFBGA |
