تفاصيل المنتج:
|
| رقم الجزء: | IRFB7730PBF | Vds - جهد انهيار مصدر التصريف: | 75 فولت |
|---|---|---|---|
| معرف -التصريف المستمر الحالي: | 195 أ | Rds على مقاومة مصدر الصرف: | 2.6 مللي أوم |
| Qg - رسوم البوابة: | 271 ن.س | Pd - تبديد الطاقة: | 375 واط |
IRFB7730PBF Integrated Circuit Chip 75V 195A StrongIRFET N-Channel MOSFET Transistors
Product Description Of IRFB7730PBF
IRFB7730PBF is an N-channel enhancement-mode power MOSFET from the StrongIRFET™ series, designed specifically for low-on-resistance, high-current, high-reliability low-frequency (<100 kHz) applications.
Specification Of IRFB7730PBF
|
Series
|
HEXFET®
|
|
Packaging
|
Tube
|
|
Part Status
|
Active
|
|
FET Type
|
N-Channel
|
|
Technology
|
MOSFET (Metal Oxide)
|
|
Drain to Source Voltage (Vdss)
|
75 V
|
|
Current - Continuous Drain (Id) @ 25°C
|
195A (Tc)
|
|
Drive Voltage (Max Rds On, Min Rds On)
|
6V, 10V
|
|
Rds On (Max) @ Id, Vgs
|
2.6mOhm @ 100A, 10V
|
|
Vgs(th) (Max) @ Id
|
3.7V @ 250µA
|
|
Gate Charge (Qg) (Max) @ Vgs
|
407 nC @ 10 V
|
|
Vgs (Max)
|
±20V
|
|
Input Capacitance (Ciss) (Max) @ Vds
|
13660 pF @ 25 V
|
|
Power Dissipation (Max)
|
375W (Tc)
|
|
Operating Temperature
|
-55°C ~ 175°C (TJ)
|
|
Mounting Type
|
Through Hole
|
|
Supplier Device Package
|
TO-220AB
|
|
Package / Case
|
TO-220-3
|
Benefits Of IRFB7730PBF
Improved gate, avalanche and dynamic dV/dt ruggedness
Fully characterized capacitance and avalanche SOA
Enhanced body diode dV/dt and dI/dt capability
Optimized for 10 V gate-drive voltage (called normal level)
Silicon optimized for applications switching below <100 kHz
Softer body-diode compared to previous silicon generation
Industry standard through-hole power package
High-current carrying capability package (up to 195 A, die-size dependent)
Capable of being wave-soldered
Applications Of IRFB7730PBF
Brushed motor drive applications
BLDC motor drive applications
Battery powered circuits
Half-bridge and full-bridge topologies
Synchronous rectifier applications
Resonant mode power supplies
OR-ing and redundant power switches
DC/DC and AC/DC converters
DC/AC inverters
