TLE8201R Integrated Circuit Chip Automotive Door Module Power IC PG-DSO-36

TLE8201R Integrated Circuit Chip Automotive Door Module Power IC PG-DSO-36​​

Product Description Of TLE8201R

TLE8201R is an Application Specific Standard Product for automotive door-module applications. It includes all the power stages necessary to drive the loads in a typical front door application, i.e. central lock, deadlock or mirror fold, mirror position, mirror defrost and 5W or 10W lamps, e.g for turn signal, courtesy/warning or control panel illumination. It is designed as a monolithic circuit in Infineons mixed technology SPT which combines bipolar and CMOS control circuitry with DMOS power devices.

Specification Of TLE8201R

Features Of TLE8201R

• Full bridge (150mΩ) for main doorlock motor
• Two half-bridges (400mΩ) for deadbolt and mirror position motor or mirror fold motor
• Two half-bridges (800mΩ) for mirror position
• High-side switch (100mΩ) for mirror defrost
• Four high-side switches (500mΩ) for 5W and 10W lamps
• Current sense analog output with multiplex
• All outputs with short circuit protection and diagnosis
• Over-temperature protection with warning
• Open load diagnosis for all outputs
• Charge pump-Output for n-channel MOS-FET reverse-polarity protection
• Very low current consumption in sleep mode
• Standard 16-bit SPI for control and diagnosis
• Over-and Undervoltage Lockout
• Power-SO package with full-size heatslug for excellent low thermal resistance
