تفاصيل المنتج:
|
| رقم الجزء: | TPSM82823SILR | مسلسل: | ميكروسيب |
|---|---|---|---|
| الجهد الناتج: | 600 مللي فولت إلى 4 فولت | تيار الإخراج: | 3 أ |
| عدد المخرجات: | 1 الإخراج | تبديل التردد: | 4 ميجا هرتز |
TPSM82823SILR Integrated Circuit Chip 3A Step-Down Converter MicroSiP™ Power Module
Product Description Of TPSM82823SILR
TPSM82823SILR is 3A, step-down converter MicroSiP™ power modules optimized for small solution size and high efficiency. The power modules integrate a synchronous step-down converter and an inductor to simplify design, reduce external components and save PCB area.
Specification Of TPSM82823SILR
|
Type
|
Non-Isolated PoL Module
|
|
Number of Outputs
|
1
|
|
Voltage - Input (Min)
|
2.4V
|
|
Voltage - Input (Max)
|
5.5V
|
|
Voltage - Output 1
|
0.6 ~ 4V
|
|
Current - Output (Max)
|
3A
|
|
Applications
|
ITE (Commercial)
|
|
Features
|
Adjustable Output, Remote On/Off
|
|
Operating Temperature
|
-40°C ~ 125°C
|
|
Efficiency
|
95%
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
10-TFDFN Module
|
|
Size / Dimension
|
0.10" L x 0.08" W x 0.04" H (2.5mm x 2.0mm x 1.1mm)
|
|
Supplier Device Package
|
10-uSIP (2.5x2)
|
Features Of TPSM82823SILR
1.1-mm profile MicroSiP™ power module
CISPR 11 class B compliant
Up to 95% efficiency
2.4-V to 5.5-V input voltage range
0.6-V to 4-V adjustable output voltage
Fixed output voltages available: 1.2-V, 1.8-V, 2.5-V and 3.3-V
4-µA operating quiescent current
DCS-control topology
Power save mode option available for light load efficiency
Forced-PWM option available for CCM operation
100% duty cycle for lowest dropout
Hiccup short circuit protection
Output discharge
Power good output with window comparator
Integrated soft start-up
Overtemperature protection
2.0-mm × 2.5-mm × 1.1-mm 10-pin µSiL package
12 mm2 total solution size (for the fixed output voltage versions)
Applications Of TPSM82823SILR
Optical modules
Machine vision
Industrial PCs
PLCs
Wired Networking
