تفاصيل المنتج:
|
| رقم الجزء: | AD7740YRMZ | التردد الكامل: | 500 كيلو هرتز |
|---|---|---|---|
| INL - اللاخطية المتكاملة: | +/- 0.012% معدل الاستقرار المالي | مقياس كامل: | ± 50 جزء في المليون / درجة مئوية |
| يكتب: | الجهد إلى التردد | درجة حرارة التشغيل: | -40 درجة مئوية ~ 105 درجة مئوية |
AD7740YRMZ Integrated Circuit Chip Low Power Synchronous Voltage-To-Frequency Converter MSOP-8
Product Description Of AD7740YRMZ
AD7740YRMZ is a low-cost, ultrasmall synchronous Voltage-to-Frequency Converter (VFC). It works from a single 3.0 V to 3.6 V or 4.75 V to 5.25 V supply consuming 0.9 mA. The AD7740 is available in an 8-lead SOT-23 and also in an 8-lead MSOP package. Small package, low cost and ease of use were major design goals for this product. The part contains an on-chip 2.5 V bandgap reference but the user may overdrive this using an external reference. This external reference range includes VDD.
Specification Of AD7740YRMZ
|
Type
|
Voltage to Frequency
|
|
Frequency - Max
|
1 MHz
|
|
Full Scale
|
±50ppm/°C
|
|
Linearity
|
±0.012%
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
|
|
Supplier Device Package
|
8-MSOP
|
Features Of AD7740YRMZ
Synchronous operation
Full-scale frequency set by external system clock
8-lead SOT-23 and 8-lead MSOP packages
3 V or 5 V operation
Low power: 3 mW (Typ)
Nominal input range: 0 to VREF
True –150 mV capability without charge pump
VREF range: 2.5 V to VDD
Internal 2.5 V reference
1 MHz max input frequency
Selectable high impedance buffered input
Minimal external components required
Applications Of AD7740YRMZ
Isolation of high common-mode voltages
Low-cost analog-to-digital conversion
Battery monitoring
Automotive sensing
