تفاصيل المنتج:
|
| رقم الجزء: | INA4180A1IPWR | عدد الدوائر: | 4 |
|---|---|---|---|
| معدل الانحراف: | 2V / µs | احصل على منتج النطاق الترددي: | 350 كيلو هرتز |
| -3db النطاق الترددي: | 350 كيلو هرتز | التيار - تحيز المدخلات: | 80 |
INA4180A1IPWR current sense amplifiers are designed for cost-optimized applications. These devices are part of a family of current-sense amplifiers (also called current-shunt monitors) that sense voltage drops across current-sense resistors at common-mode voltages from -0.2 V to +26 V, independent of the supply voltage.
| Number of Channels | 4 Channel |
| GBP - Gain Bandwidth Product | 350 kHz |
| Vcm - Common Mode Voltage | 12 V |
| CMRR - Common Mode Rejection Ratio | 100 dB |
| Ib - Input Bias Current | 80 uA |
| Vos - Input Offset Voltage | 100 uV |
| Supply Voltage - Max | 5.5 V |
| Supply Voltage - Min | 2.7 V |
| Operating Supply Current | 900 uA |
| Gain Error | 0.1 % |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
| 3 dB Bandwidth | 350 kHz |
| en - Input Voltage Noise Density | 40 nV/sqrt Hz |
| Gain V/V | 20 V/V |
| Input Type | Common Mode |
| Ios - Input Offset Current | 50 nA |
| Moisture Sensitive | Yes |
| Output Current per Channel | 8 mA |
| SR - Slew Rate | 2 V/us |
| Unit Weight | 118.600 mg |
