تفاصيل المنتج:
|
| رقم الجزء: | OPA365AIDBVR | عدد القنوات:: | 1 قناة |
|---|---|---|---|
| نوع الإخراج: | السكك الحديدية إلى السكك الحديدية | معدل الانحراف: | 25V / µs |
| احصل على منتج النطاق الترددي: | 50 ميغا هيرتز | التيار - تحيز المدخلات: | 0.2 باسكال |
OPA365AIDBVR is a zero-crossover series, rail-to-rail, high-performance CMOS operational amplifier optimized for very low voltage, single-supply applications. With rail-to-rail input/output, low-noise (4.5 nV/√Hz), and high-speed operation (50-MHz gain bandwidth), this device is an excellent choice for driving sampling analog-to-digital converters (ADCs).
| Parameter | Value |
|---|---|
| Number of Channels | 1 Channel |
| GBP - Gain Bandwidth Product | 50 MHz |
| SR - Slew Rate | 25 V/μs |
| Vos - Input Offset Voltage | 200 μV |
| Ib - Input Bias Current | 10 pA |
| Supply Voltage - Max | 5.5 V |
| Supply Voltage - Min | 2.2 V |
| Operating Supply Current | 4.6 mA |
| Output Current per Channel | 65 mA |
| CMRR - Common Mode Rejection Ratio | 120 dB |
| en - Input Voltage Noise Density | 4.5 nV/√Hz |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +125°C |
| In - Input Noise Current Density | 4 fA |
| PSRR - Power Supply Rejection Ratio | 100 dB |
| Unit Weight | 6.300 mg |
| Part Number | Package |
|---|---|
| INA241A5QDGKRQ1 | 8-TSSOP |
| INA296B3IDR | 8-SOIC |
| INA241A3IDR | 8-SOIC |
| INA296A3IDR | 8-SOIC |
| INA241B4IDR | 8-SOIC |
| INA296A1IDR | 8-SOIC |
| INA241B1IDR | 8-SOIC |
| INA296A2IDR | SOIC-8 |
| INA241A4QDGKRQ1 | MSOP-8 |
| INA296B2IDR | SOIC-8 |
| INA241B3IDR | 8-SOIC |
| INA241A2QDDFRQ1 | SOT-23-8 |
| INA296B3QDGKRQ1 | MSOP-8 |
| INA241B3QDGKRQ1 | MSOP-8 |
| INA241B4QDGKRQ1 | MSOP-8 |
| INA296B1IDGKR | MSOP-8 |
| INA241B5QDGKRQ1 | MSOP-8 |
| INA296A1QDGKRQ1 | MSOP-8 |
| INA296B5QDGKRQ1 | MSOP-8 |
| INA241B2QDGKRQ1 | MSOP-8 |
| INA241B5IDGKR | MSOP-8 |
| INA296B4QDGKRQ1 | MSOP-8 |
| INA296B2QDGKRQ1 | MSOP-8 |
| TUSB1142IRNQR | 40-WQFN |
| TUSB1104IRNQR | 40-WQFN |
| TUSB1104RNQR | 40-WQFN |
| TPS65982BBZBHR | 96-VFBGA |
| TPS25842QWRHBRQ1 | 32-VQFN |
| TUSB1046AI-DCIRNQR | 40-WQFN |
| TPS25810TWRVCRQ1 | 20-WQFN |
Yes, all products are original, new original import is our purpose.
We are ISO 9001:2015 Certified Company and member of ERAI.
Yes, we support sample order and small order. Sample cost is different according to your order or project.
We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
