تفاصيل المنتج:
|
| رقم الجزء: | SI8660BD-B-ISR | عدد القنوات: | 6 |
|---|---|---|---|
| المدخلات - الجانب 1/الجانب 2: | 6/0 | الجهد - العزلة: | 5000Vrms |
| الوضع المشترك للمناعة العابرة (الحد الأدنى): | 35 كيلو فولت / µs | معدل البيانات: | 150 ميجابت في الثانية |
SI8660BD-B-ISR Digital Isolators offer highly reliable, high-speed operation for demanding applications with isolation ratings up to 5kV. These digital isolators replace optocouplers in applications requiring robust operation and high levels of insulation protection, such as industrial automation and drives, motor control, and medical systems.
The SI8660BD-B-ISR provides isolation solutions for isolated AC-DC and DC-DC power supplies, solar panel microinverters, data communications systems, and hybrid electric vehicles (HEVs). These isolators deliver a data rate of 150Mbps across a temperature range of -40°C to +125ºC, with ultra-low-power operation of less than 1.6mA per channel at 1Mbps for energy-efficient system design.
| Specification | Value |
|---|---|
| Number of Channels | 6 Channel |
| Polarity | Unidirectional |
| Data Rate | 150 Mb/s |
| Isolation Voltage | 5000 Vrms |
| Isolation Type | Capacitive Coupling |
| Supply Voltage - Max | 5.5 V |
| Supply Voltage - Min | 2.375 V |
| Propagation Delay Time | 8 ns |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +125°C |
| Forward Channels | 6 Channel |
| Maximum Fall Time | 4 ns |
| Maximum Rise Time | 4 ns |
| Moisture Sensitive | Yes |
| Power Dissipation | 415 mW |
| Pulse Width | 5 ns |
| Pulse Width Distortion | 4.5 ns |
| Reverse Channels | 0 Channel |
| Shutdown | Shutdown |
| Unit Weight | 547.510 mg |
