تفاصيل المنتج:
|
| رقم الجزء: | MC33153PG | الجهد - العرض: | 11 فولت ~ 20 فولت |
|---|---|---|---|
| الجهد المنطقي - VIL ، VIH: | 1.2 فولت، 3.2 فولت | التيار - ذروة الإخراج (المصدر ، المغسلة): | 1 أ ، 2 أ |
| وقت الارتفاع / الخريف (TYP): | 17 ن، 17 ن | درجة حرارة التشغيل: | -40 درجة مئوية ~ 150 درجة مئوية (TJ) |
The MC33153PG is specifically designed as an IGBT driver for high power applications including AC induction motor control, brushless DC motor control, and uninterruptible power supplies. While optimized for driving discrete and module IGBTs, this device offers a cost-effective solution for driving power MOSFETs and bipolar transistors. Device protection features include the choice of desaturation or overcurrent sensing and undervoltage detection. Available in dual-in-line and surface mount packages.
| Type | Half Bridge |
|---|---|
| Output Current | 20 mA |
| Operating Supply Current | 7.9 mA |
| Operating Temperature Range | -40°C to +105°C |
| Mounting Style | Through Hole |
| Package/Case | PDIP-8 |
| Supply Voltage - Max | 15 V |
| Unit Weight | 1 g |
