تفاصيل المنتج:
|
| رقم الجزء: | L6387ED013TR | الجهد - العرض: | 17 فولت (الحد الأقصى) |
|---|---|---|---|
| الجهد المنطقي - VIL ، VIH: | 1.5 فولت، 3.6 فولت | التيار - ذروة الإخراج (المصدر ، المغسلة): | 400 مللي أمبير، 650 مللي أمبير |
| الجهد الجانبي العالي - الحد الأقصى (التمهيد): | 600 فولت | درجة حرارة التشغيل: | -45 درجة مئوية ~ 125 درجة مئوية (تي جي) |
L6387ED013TR is a simple and compact high voltage gate driver, manufactured with the BCD™ "offline" technology, and able to drive a half-bridge of power MOSFET or IGBT devices. The high-side (floating) section is enabled to work with voltage rail up to 600 V. Both device outputs can independently sink and source 650 mA and 400 mA respectively and cannot be simultaneously driven high thanks to an integrated interlocking function.
L6387ED013TR device provides two input pins and two output pins and guarantees the outputs toggle in phase with inputs. The logic inputs are CMOS/TTL compatible to ease the interfacing with controlling devices.
L6387ED013TR features the UVLO protection on the VCC supply voltage and integrates the bootstrap diode, allowing a more compact and reliable solution.
| Number of Drivers | 2 Driver |
| Number of Outputs | 1 Output |
| Output Current | 650 mA |
| Supply Voltage - Min | -300 mV |
| Supply Voltage - Max | 17 V |
| Rise Time | 50 ns |
| Fall Time | 30 ns |
| Minimum Operating Temperature | -45°C |
| Maximum Operating Temperature | +125°C |
| Logic Type | CMOS, TTL |
| Maximum Turn-Off Delay Time | 105 ns |
| Maximum Turn-On Delay Time | 110 ns |
| Moisture Sensitive | Yes |
| Operating Supply Current | 320 uA |
| Pd - Power Dissipation | 750 mW |
