تفاصيل المنتج:
|
| رقم الجزء: | NSM2019-100B5F3-DSWCR | الحالي - الاستشعار: | ± 100 أ |
|---|---|---|---|
| عدد القنوات: | 1 | حساسية: | 20mV / أ |
| تكرار: | تيار مستمر ~ 320 كيلو هرتز | الخطية: | ± 0.2 ٪ |
| إبراز: | ±100A Sensor IC,1-Channel Hall Effect Current Sensor,Bidirectional Integrated Current Sensor |
||
NSM2019-100B5F3-DSWCR Sensor IC Integrated 1-Channel Hall Effect Bidirectional Current Sensor Product Overview Of NSM2019 NSM2019 is an integrated path current sensor with a very low on-resistance of 0.27mΩ, significantly reducing heat loss on the chip. Key Features Of NSM2019 20~200A wide current range AC/DC input compatibility 3.3V/5V single power supply 0.27mΩ low input conduction impedance ±2% current measurement accuracy 1.5μs response time 320kHz signal bandwidth
